Getting Acquainted with the Calibrator
9
Table 3. Input/Output Terminals and Connectors
No Name Description
A
Pressure module
connector
Connects the calibrator to a pressure module or the calibrator to a PC for a remote
control connection.
B, C
MEASURE V, mA
terminals
Input terminals for measuring voltage, current, and supplying loop power.
D
TC input/output Terminal for measuring or simulating thermocouples. This terminal accepts a miniature
polarized thermocouple plug with flat, in-line blades spaced 7.9 mm (0.312 in) center to
center.
E, F
SOURCE/ MEASURE
V, RTD, Hz, Ω
terminals
Terminals for sourcing or measuring voltage, resistance, frequency, and RTDs.
G, H
SOURCE/ MEASURE
mA terminals, 3W, 4W
Terminals for sourcing and measuring current, and performing 3W and 4W RTD
measurements.
