Fluke 77 Series III User Manual

List of Replaceable Parts
Parts Lists
4
4-5
Table 4-1. Final Assembly
Ref Des Description Fluke PN Qty Notes
A1 MAIN PCA NA 1
BT1 BATTERY,9V,0-15MA 696534 1
DS1 LCD,3.75 DIGIT,BAR GRAPH,MULTIPLED 602927 1
F1W FUSE,.406x1.375,0.440A,1000V,FAST 943121 1
F2W FUSE,.406X1.5, 11A, 1000V, FAST 803293 1
H1 SCREW,PH,P,THD FORM,STL,4-24,.250 519116 1
H2 SCREW,PH,P,AM THD FORM,STL,4-14,375 448456 5
H7 SCREW,PH,P,AM THD FORM,STL,5-14,.759 832246 4
LS1 AF TRANSD,PIEZO,20MM,600MW,6KHZ 642991 1
MP4 HOLDER,PROBE 648748 1
MP5 STAND,TILT 648961 1
MP6 LABEL,WINDOW 844337 1
MP9 SHIELD,AC 648755 1
MP10 SPRING,DETENT 822643 4
MP11 KNOB,SWITCH 648706 1
MP12 ADAPTER,SHAFT 649175
MP14 CASE BOTTOM ASSEMBLY 659786 1
MP16 SHOCK ABSORBER 428441 1
MP17 CASE TOP PAD XFR 648763 1
MP18 WINDOW, LCD 648714 1
MP19 COVER,INTERNAL 648722 1
MP20 MASK,BRACKET,77-3 WITH LOGO 648771 1
MP21 CONN,ELASTOMERIC,LCD TO PWB,1.900 L 650264 2
MP23 SHIELD,BOTTOM 648839 1
MP32 TEST LEADS TL75 1
MP40 CONTACT,ANNUNCIATOR 642983 1
S2 KEYPAD 648847 1
TM1 77/75/23/21 SERIES III INSTRUCTION
SHEET
686571 1
TM2 77 SERIES III SERVICE MANUAL 800604 1
W To ensure safety, use exact replacement only.

Fluke 77 Series III Specifications

General

Diode Test	Yes
Continuity Beeper	Yes
Battery Type	9V
Safety Rating	CAT III 600V
Display	LCD, 4000 counts
Voltage DC	1000V
Voltage AC	1000V
Current DC	10A
Current AC	10A
Resistance	40 MΩ
Weight	340 g
