List of Replaceable Parts
Parts Lists
4
4-7
Table 4-2. A1 Main PCA
Ref Des Description PN Qty. Notes
C1 CAP,POLYES,0.0UF, ±10%,1000V 822361 1
C2,C3 CAP,CER,0.1UF, ±10%,25v,X7R 942529 2
C4 CAP,TA,2.2UF, ±20%,20V 854760 1
C5,C6 CAP,POLYCA,0.027UF, ±10%,63V 720979 2
C7 CAP,TA,0.47UF, ±20%,25V 876180 1
C8 CAP,POLYPR,0.033UF, ±10%,63V 721050 1
C9 CAP,TA,10UF, ±20%,10V,3528 603032 1
C10 CAP,CER,0.1UF, ±10%,25V,XR7 942529 1
C11 CAP,TA,2.2UF, ±20%,6V,3216 930248 1
C12 CAP,CER,47PF, ±5%,50V,C0G 494633 1
C13 CAP,CER,0.22UF,+80%,-20%,50V,Y5V 740597 1
C14,C15 CAP,CER,33PF, ±5%,50V,C0G 603172 1
C16 CAP,CER,47PF, ±5%,50V,COG 494633 1
CR1,CR2 * DIODE,SI,75V,250MA,SOT-23 830489 2
J1-4 RECEPTACLE,INPUT 658580 4
Q1,Q3 * XSTR,SI,NPN,25V,.3W,SEL,SOT-23 821637 2
Q2 * XSTR,SI,NPN,60V,350MW,SOT-23 742676 1
R1 RES,WW,3.5K, ±5%,5W,20PPM 107695 1
R2 RES,CERM,1K, ±5%,1W,200PPM 601176 1
R3 RES,CERM,1M, ±5%,1W 655175 1
R4 RES,CF,100K, ±1%,0.25W,100PPM 769802 1
R5 RES,MF,402K, ±0.25%,0.25W,50PPM 602664 1
R6 RES,WW,4.99, ±1%,5W 642923 1
R7 RES,WW,.005, ±1%,.5W 740415 1
R8 RES,VAR,CERM,100K, ±25% 912493 1
R9,R19 RES,CERM,1M, ±1%,0.125W,100PPM 836387 2
R10 RES,CERM,1.5M, ±1%,.1W,400PPM, 602703 1
R11,12 RES,MF,10K, ±1%,0.1W,100PPM 928791 2
R13 RES,MF,44.8K, ±0.25%,0.1W,50PPM 602679 1
R14 RES,CF,61.9K, ±1%,0.125W,100PPM 821330 1
R15 RES,MF,56.2K, ±1%,0.1W,100PPM 602687 1
R16 RES,MF,205K, ±1%,0.1W,100PPM 602935 1
R17 RES,CERM,20.5K, ±0.5%,100PPM 107711 1
R18 RES,CERM,9.2K, ±0.5%,100PPM 107745 1
RT1 THERMISTOR,POS,1.1K, ±+-20%,25 C 602995 1
RV1-,RV3 VARISTOR,910, ±+-10%,1.0MA 876193 3
S1 SWITCH,ROTARY 642918 1
U1 * IC CHIP 791269 1
U2 * IC, CMOS SM5A 603669 1
VR1 * IC, 1.23V,150 PPM T.C.,BANDGAP 634451 1
XBT1 BATTERY CONNECTOR 825976 1
XF1 CONTACT, FUSE 659524 2
