Fluke 771 User Manual

771
Calibration Manual
4
Specifications
Current Ranges ±20.99 mA ±21.0 mA - ±99.9 mA
Resolution 0.01 mA 0.1 mA
Accuracy
20.99 mA range
99.9 mA range
0.2 % reading ±5 digits
1 % reading ±5 digits
Maximum Reading ±99.9 mA
Influence of Earth’s Field < 0.20 mA
Battery 2 AA 1.5 V Alkaline, IEC LR6
Working hours 45 hours
Size (H X W X L) 59 mm x 38 mm x 212 mm (2.32 in x 1.49 in x 8.34 in)
(with clamp nested)
Weight 260 g (9.17 oz) (Including battery)
Operating Temperature -10 to 50 °C
(14 to 122 °F)
Storage Temperature -25 to 70 °C
(-13 to 158 °F)
Operating Humidity < 90 % @ <30 °C (86 °F)
<75 % @ 30 to 50 °C (86 to 122 °F)
Operating Altitude 0 to 2000 m (1.24 miles)
Storage Altitude None
IP Rating IP 40
Vibration Requirements Random 2 g, 5 to 500 Hz
EMI, RFI, EMC Meets all applicable requirements in EN 61326-1
Temperature Coefficients 0.1x(specified accuracy)/°C
(< 18 °C or > 28 °C)
Measurement Category IEC 61010-1
61010-2-032
CAT II 300 V
CAT II Equipment is designed to protect against transients from
energy-consuming equipment supplied from the fixed installation,
such as TVs, PCs, portable tools, and other household appliances.
Agency Approvals
P, ), ;, FCC
N10140
1.800.868.7495info@Fluke-Direct.ca
Fluke-Direct.ca

Fluke 771 Specifications

General

Operating altitude	0 - 2000 m
Storage temperature (T-T)	-25 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Product type	Digital multimeter
Product color	Grey, Red, Yellow
DC current range	0.021 - 0.1 A
Resolution (DC current)	0.21 µA
Basic accuracy (DC current)	1% + 5 counts
Battery type	AA
Power source	Battery
Battery voltage	1.5 V
Battery technology	Alkaline
Number of batteries supported	2

Weight and Dimensions

Depth	38 mm
Width	59 mm
Height	212 mm
Weight	260 g
