787
Users Manual
42
Diode Test and Continuity Test
Diode test indication: display voltage drop: 0.2 mA
nominal test current at 0.6V: 2.4V full scale, accuracy
±(2% + 1 count)
Continuity test indication: continuous audible tone for
test resistance <100 Ω
Open circuit voltage: <3.9 V
Short circuit current: 1.2 mA typical
Overload protection: 1000 V rms
DC Current Output
Source mode:
Span: 0 mA or 4 mA to 20 mA, with overrange to 24 mA
Accuracy: 0.05 % of span
Compliance voltage: 12 V with battery voltage >8.5 V
Simulate Mode:
Span: 0 mA or 4 mA to 20 mA, with overrange to 24 mA
Accuracy: 0.05 % of span
Loop voltage: 24 V nominal, 30 V maximum, 15 V
minimum
Compliance voltage: 21 V for 24 V supply
Burden voltage: <3 V
