20 80i-110s Instruction Manual
IF YOUR CURRENT PROBE DOES NOT
WORK
If the 80i-110s does not perform properly, use the following steps to help isolate
the problem:
1. Test the battery: be sure that the green ON-indicator lights when you select
the 10 mV/A range or the 100 mV/A range.
2. Inspect the jaw mating surface for cleanliness. If any foreign material is
present, the jaws will not close properly and errors will result.
3. Verify that the probe is zeroed properly. For zeroing be sure that the
ScopeMeter test tool or oscilloscope is DC-coupled.
4. Verify that the function selection on the ScopeMeter test tool or oscilloscope
is correct, i.e., the display vertical resolution is not too low or too high.
REPLACEMENT PARTS
To order replacement parts in the USA, call 1-800-526-4731. To order outside the
USA, contact the nearest Service Center. Use the following part numbers:
Order Fluke Part PM9081/001 BNC-to-Banana Adapter to use the Current Probe
with a digital multimeter.
Description Part Number
•
9 Volt Battery (IEC 6LR61) 4822 138 10116
•
Battery Cover 5322 447 92322
•
Users Manual 4822 872 00631
•
Quick Reference Card 4822 872 00633
