Fluke 87V MAX User Manual

Digital Multimeter
Features
5
Table 3. Pushbuttons (cont.)
Button
Switch
Position
Function

Continuity

MIN MAX
recording
Hz, Duty
Cycle
Turns the continuity beeper on and off
Switches between Peak (250 μs) and Normal (100 ms) response times.
Toggles the meter to trigger on positive or negative slope.

Any switch
position Turns the button backlight and display backlight on, makes them brighter, and turns them off.
Hold  down for one second to enter the HiRes digit mode. The “HiRes” icon appears on the
display. To return to the 3-1/2 digit mode, hold
 down for one second. HiRes=19,999

Any switch
position
Starts recording of minimum and maximum values. Steps the display through MAX, MIN, AVG
(average), and present readings. Cancels MIN MAX (hold for 1 second)
1.800.561.8187info@Fluke-Direct.ca
Fluke-Direct.ca

Fluke 87V MAX Specifications

General

Waterproof	Yes
Product type	Digital multimeter
Product color	Yellow
Frequency range	0.5 - 199.99 kHz
DC voltage range	0.1 - 1000 V
Resistance range	0.1 - 50 Ω
Capacitance range	0.1 - 9999 nF
Measuring category	CAT III 1000V
Placement supported	Handheld multimeter
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	0.1 µA
Resolution (DC voltage)	0.1 mV
Temperature measurement range	-200 - 1090 °C
International Protection (IP) code	IP67
Battery life	800 h
Battery type	AA
Power source	Battery
Number of batteries supported	3

Weight and Dimensions

Depth	215 mm
Width	600 mm
Height	101 mm
Weight	698.5 g
