Fluke 87V MAX User Manual

Digital Multimeter
Detailed Specifications
41
Detailed Specifications
For all detailed specifications:
Accuracy is specified for 2 years after calibration, at operating temperatures of 18 °C to 28 °C, with relative humidity at 0 % to 95 %.
Accuracy specifications take the form of ±([% of Reading] + [Number of least-significant digits]). For the 4 ½-digit mode, multiply the number
of least-significant digits (counts) by 10.
AC Voltage
AC conversions are ac-coupled and valid from 3 % to 100 % of range.
Range Resolution
Accuracy
45 – 65 Hz 15 – 200 Hz 200 – 440 Hz 440 Hz – 1 kHz 1 – 5 kHz 5 – 20 kHz
600.0 mV 0.1 mV
±(0.7 % + 4)
±(1.0 % + 4)
[1]
±(2 % + 4)
±(2 % + 20)
[2]
6.000 V 0.001 V
60.00 V 0.01 V
±(0.7 % + 2)
±(2 % + 4)
[3]
Unspecified
600.0 V 0.1 V Unspecified
1000 V 1 V Unspecified Unspecified
Low-Pass Filter
±(1.0 % + 4)
[1]
+1.0 % + 4
-6.0 % - 4
[4]
Unspecified Unspecified Unspecified
[1] Below 30 Hz, use smoothing function. Below 20 Hz add 0.6 %.
[2] Below 10 % of range, add 12 counts.
[3] Frequency range: 1 to 2.5 kHz
[4] Specification increases from -1 % to -6 % at 440 Hz when filter is used.
1.800.561.8187info@Fluke-Direct.ca
Fluke-Direct.ca

Fluke 87V MAX Specifications

General

Waterproof	Yes
Product type	Digital multimeter
Product color	Yellow
Frequency range	0.5 - 199.99 kHz
DC voltage range	0.1 - 1000 V
Resistance range	0.1 - 50 Ω
Capacitance range	0.1 - 9999 nF
Measuring category	CAT III 1000V
Placement supported	Handheld multimeter
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	0.1 µA
Resolution (DC voltage)	0.1 mV
Temperature measurement range	-200 - 1090 °C
International Protection (IP) code	IP67
Battery life	800 h
Battery type	AA
Power source	Battery
Number of batteries supported	3

Weight and Dimensions

Depth	215 mm
Width	600 mm
Height	101 mm
Weight	698.5 g
