Fluke 87V MAX User Manual

87V MAX
Users Manual
2
Features
Tables 1 through 4 briefly describe the features of the Meter.
Table 1. Inputs
gaq112.emf
Terminal Description
A
Input for 0 A to 10.00 A current (10 - 20 A overload for 30 seconds maximum), current frequency, and duty
cycle measurements.

Input for 0 μA to 400 mA current measurements (600 mA for 18 hrs) and current frequency and duty cycle.
COM
Return terminal for all measurements.

Input for voltage, continuity, resistance, diode, capacitance, frequency, temperature, and duty cycle
measurements.
1.800.561.8187info@Fluke-Direct.ca
Fluke-Direct.ca

Fluke 87V MAX Specifications

General

Waterproof	Yes
Product type	Digital multimeter
Product color	Yellow
Frequency range	0.5 - 199.99 kHz
DC voltage range	0.1 - 1000 V
Resistance range	0.1 - 50 Ω
Capacitance range	0.1 - 9999 nF
Measuring category	CAT III 1000V
Placement supported	Handheld multimeter
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	0.1 µA
Resolution (DC voltage)	0.1 mV
Temperature measurement range	-200 - 1090 °C
International Protection (IP) code	IP67
Battery life	800 h
Battery type	AA
Power source	Battery
Number of batteries supported	3

Weight and Dimensions

Depth	215 mm
Width	600 mm
Height	101 mm
Weight	698.5 g
