Fluke 87V MAX User Manual

Digital Multimeter
Features
3
Table 2. Rotary Switch Positions
Switch Position Function
Any Position When the Meter is turned on, the Meter model number briefly appears on the display.

AC voltage measurement
Press
 (yellow) for low-pass filter ()
 DC voltage measurement

600 mV dc voltage range
Press  (yellow) for temperature ()
 Press  for continuity test.
e Resistance measurement
Press  (yellow) for capacitance measurement.
 Diode test

AC current measurements from 0 mA to 10.00 A
Press
 (yellow) for dc current measurements, from 0 mA to 10.00 A.

AC current measurements from 0 μA to 6000 μA
Press
 (yellow) for dc current measurements from 0 μA to 6000 μA.
1.800.561.8187info@Fluke-Direct.ca
Fluke-Direct.ca

Fluke 87V MAX Specifications

General

Waterproof	Yes
Product type	Digital multimeter
Product color	Yellow
Frequency range	0.5 - 199.99 kHz
DC voltage range	0.1 - 1000 V
Resistance range	0.1 - 50 Ω
Capacitance range	0.1 - 9999 nF
Measuring category	CAT III 1000V
Placement supported	Handheld multimeter
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	0.1 µA
Resolution (DC voltage)	0.1 mV
Temperature measurement range	-200 - 1090 °C
International Protection (IP) code	IP67
Battery life	800 h
Battery type	AA
Power source	Battery
Number of batteries supported	3

Weight and Dimensions

Depth	215 mm
Width	600 mm
Height	101 mm
Weight	698.5 g
