Product Familiarization
7
Center Point and Accessory Mount
Figure 1 shows features that help to layout reference marks. The vertical laser is centered 1.25 in (31.75 mm)
from both sides of the Product. To stabilize the Product and view the laser that points down, use the accessory
mount to secure the Product to the magnetic L-bracket, the floor stand, or a tripod.
Figure 1. Center Point and Accessory Mount
31.75 mm
1.25 in
31.75 mm
1.25 in
1/4 -20
