Fluke PLS 6R - Existing Item Plumb Check

6R, 6G, 180R, 180G
Users Manual
12
Existing Item Plumb Check
To determine if an existing item is plumb:
1. Point either the up or down laser at the target area.
2. Measure the distance from the item to the laser at various distances from the Product. See Figure 6.
If the measurements are the same, the item is plumb.
Figure 6. Existing Item Plumb Check
=
=
2
1
OK
2
1
