Fluke PLS 6R User Manual

6R, 6G, 180R, 180G
Users Manual
10
Existing Item Alignment
To determine if an existing item is level or aligned:
1. Put the bottom of the Product on a stable surface.
2. Aim the horizontal or vertical laser at the target area.
3. Measure the distance from the item to the laser at various distances from the Product. See Figure 4.
If the measurements are the same, the item is level or aligned.
Figure 4. Existing Item Alignment
1
21
=
=OK
2

Fluke PLS 6R Specifications

General

Brand	Fluke
Model	PLS 6R
Category	Laser Level
Language	English
