6R, 6G, 180R, 180G
Users Manual
20
Working range
Point laser (6R and 6G only) ≤30 m (100 ft)
Line laser
Without SLD ≤15 m (50 ft)
With SLD 6 m to 60 m (20 ft to 200 ft)
Accuracy ≤3 mm at 10 m (≤1/8 in at 30 ft)
Laser leveling 4 °
Point laser diameter (6R and 6G only) ≤4 mm at 5 m
Line laser width ≤2 mm at 5 m
Temperature
Operating -10 °C to 50 °C (14 °F to 122 °F)
Storage
With batteries -18 °C to 50 °C (-0.4 °F to 122 °F)
Without batteries -20 °C to 70 °C (-13 °F to 158 °F)
Relative humidity
0 % to 90 % (0 °C to 35 °C)
0 % to 75 % (35 °C to 40 °C)
0 % to 45 % (40 °C to 50 °C)
Size (H x W x L) 116 mm x 64 mm x 104 mm (4.6 in x 2.5 in x 4.1 in)
Weight ∼0.6 kg (1.3 lb)
Drop test 1m
Safety IEC 61010-1: Pollution Degree 2
Laser IEC 60825-1:2014 Class 2
Light source Semiconductor laser diode
Max output power <1mW
Wavelength
Red 635 nm ±5nm
Green 525 nm ±5nm
Electromagnetic Compatibility (EMC)
International IEC 61326-1: Basic Electromagnetic Environment
CISPR 11: Group 1, Class B
Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the
internal function of the equipment itself.
Class B: Equipment is suitable for use in domestic establishments and in establishments directly connected to a low voltage pow
er
supply network which supplies buildings used for domestic purposes.
Emissions that exceed the levels required by CISPR 11 can occur when the equipment is connected to a test object
Korea (KCC) Class B Equipment (Broadcast communications equipment for home)
USA (FCC)
47 CFR 15 subpart B. This product is considered an exempt device per clause
15.103.
