CONTROL OPERATING THE
CONTROL
DISPLAY GPIB-CODE
Move function cursor to
WIDTH A
WIDTH A or
PWIDTH A
MEAS TIME is operated
in the same way as the
func-tions control, see
page 8.
MTIME <num>
where <num>
is the time in
seconds.
Range:
10 ms to 10 s.
0 = Single
Move the measuring-
time cursor to SINGLE
MTIME 0
Move the measuring-
time cursor to 0.2 s
MTIME 0.2
Move the measuring-
time cursor to 1 s
MTIME 1
Move the measuring -
time cursor to 10 s
MTIME 10
