For IBM PC with PM 2201
Example 1
The following example runs on an IBM compatible PC
equipped with Fluke PM 2201 GPIB interface. The instal-
lation and starting up of the PC program is not de-
scribed, only the application program. Line 1 to 100
must contain the declaration described in the PM 2201
manual.
The program sets up the counter for 10 Period A meas-
urements and presents the average result on the screen.
100 ’DEMO PROGRAM (NO 1)
110 ’PM6669 AND IBM PC
120 ’WITH PM2201 GPIB INTERFACE
130 ’AS CONTROLLER
140 CLS ’CLEAR SCREEN
150 AD=7 ’ADAPTOR NUMBER
160 ADDR=710 ’COUNTER ADDRESS
170 SC=1 ’SYSTEM CONTROLLER
180 RES$ = SPACE$(25) ’RESULT
190 ACT = 0 ’# READ CHARACTERS IN RES$
200 MAX = 24 ’MAX CHARACTERS TO READ IN
RES$
210 CALL IOINIT(AD,SC) ’INIT INTERFACE
220 TIME=10 ’TIMEOUT AFTER 10 SECONDS
230 CALL IOTIMEOUT (AD,TIME) ’SET TIMEOUT
240 CALL IOCLEAR(ADDR) ’SEND SDC
250 ’SELECT PERIOD A, TRIGGERED MODE
260 ’AND 1 S MEASURING-TIME
270 SEND$ = "PER A,TRIG ON,MTIME 1"
280 LENGTH=LEN(SEND$)
290 CALL IOOUTPUTS(ADDR,SEND$,LENGTH)
300 Z=0
310 ’INPUT 10 SAMPLES
320 FOR i = 1 TO 10
330 CALL IOTRIGGER(ADDR) ’TRIGGER COUNTER
340 CALL IOENTERS(ADDR,RES$,MAX,ACT) ’READ
RESULT
350 Z = Z + VAL(MID$(RES$,8,13))
360 NEXT I
370 PRINT "AVERAGE:";Z/10;"S"
380 CALL IOLOCAL(ADDR) ’GO TO LOCAL
390 END
Example of a result:
AVERAGE: 9.98004E-06 S
OK
Example 2
This program example illustrates the ‘program data out’
feature of PM 6669. By asking a set of queries, the
counter responds with its current setup. The output for-
mat of these answers to the queries is identical to the
programming command format. The answers can be
stored and used later for reprogramming (bus learn).
100 ’DEMO PROGRAM
110 ’PM6669 AND IBM PC WITH PM2201
120 GPIB INTERFACE AS CONTROLLER
130 AD=7 ’ADAPTOR NUMBER
140 ADDR=710 ’COUNTER ADDRESS
150 SC=1 ’SYSTEM CONTROLLER
160 CALL IOINIT(AD,SC) ÍNIT INTERFACE
170 TIME=10 ’TIMEOUT AFTER 10 SECONDS
180 CALL IOTIMEOUT(AD,TIME)
190 CLS ’CLEAR SCREEN
200 ÁSK FOR AND PRINT PROGRAM DATA
210 PRINT "COUNTING SETTING:"
220 S$ = "FNC?"
230 GOSUB 520
240 A=1
250 GOSUB 550
260 S$ = "MEAC?"
270 GOSUB 520
280 A=2
290 GOSUB 550
300 S$ = "BUS?"
310 GOSUB 520
320 A=2
330 GOSUB 550
340 S$ = "INPA?"
350 PRINT "INPA:"
360 GOSUB 520
370 A=1
380 GOSUB 550
390 S$ = "INPB?"
400 PRINT "INPB:"
410 GOSUB 520
420 A=1
430 GOSUB 550
440 S$ = "ID?"
450 PRINT
460 PRINT "COUNTER TYPE:"
470 GOSUB 520
480 A=1
490 GOSUB 550
500 CALL IOLOCAL (ADDR) ’GO TO LOCAL
510 END
520 L=LEN(S$) ’LENGTH OF STRING TO SEND
530 CALL IOOUTPUTS(ADDR,S$,L) ÓUTPUT STRING
540 RETURN
550 FOR I = 1 TO A
560 MAX=25
570 ACT=0
580 RES$=SPACE$(25)
590 CALL IOENTERS(ADDR,RES$,MAX,ACT)
600 B$ = LEFT$(RES$,ACT)
610 PRINT B$;
620 NEXT I
630 RETURN
Example of a result:
COUNTER SETTING:
TIME A;B
MTIME1.00,FRUN ON
TOUT 00.0
MSR 000,OUTM 000
EIO OFF,SPR 010
INPA:
TRGSLP NEG
INPB:
TRGSLP POS
COUTER TYPE:
PM6669/016/22
Ok
