S IMPLIFIBER ENGLISH - 8
SIMPLIFIBER threaded
optical receiver port.
Accepts different
connector adapters.
Powers SIMPLIFIBER ON or OFF.
SHFT in conjunction with other keys executes
extended functions. REF sets the Reference.
λ increases the wavelength from 850nm to
1300nm to 1310nm to 1550nm. SHFT + dBm
switches the mode between dBm and dB.
SAVE saves test results. SHFT + DEL deletes
results.
DB-9 Serial Connector
allows attachment of a
serial cable for inter-
face with PC-based
software (Scanlink).
SIMPLIFIBER Meter
