S IMPLIFIBER ENGLISH - 16
the transmitted light.
The transmitted light can be operated
continuously or modulated. When measuring
power, use the continuous light source. When
identifying fiber cables with an identifier, use
the 2kHz modulated mode.
Press MOD to toggle between continuous and
modulated lightsource. When Continuous
Wave is selected, the LED will show a steady
light; when 2kHz (modulated) is selected, the
LED will blink.
Use this feature with all third party power
meters.
(SIMPLIFIBER 850/1300 Source) Press λ
(Lambda) to manually switch the wavelength
between 850 nm and 1300 nm. Connect the
launch cable to the appropriate port.
LED Indicators
SIMPLIFIBER
850/1300 Source has 5 red LED
indicators. The following describes the LED
activity:
