Technical Data
Hardware Data
Environment
This table shows the environment specifications of the unit.
Table 17
Item Specification
Operational temperature -20 - +50 ºC (-4 to +122 ºF)
Storage temperature -10 - +65 ºC (-14 to +149 ºF)
Humidity (noncondensing) 90% RH
Front mount: Frontal unit
This table shows the specifications of the frontal unit.
Table 18
Item Specification
Size (L x W x H) 11.30 x 7.36 x 1.73 in
Weight (total) 3.97 lb
Mounting Rectangular hole
Surface seal EPDM rubber
Connectors 4 pc. DB 9, 1 pc. DB 37
Front panel, front side IP 65
Front panel, back side IP 20
Front mount: I/O unit
This table shows the specifications of the I/O unit.
Table 19
Item
Specification
Size (L x W x H) 11.65 x 10.67 x 2.44 in
Weight (total) 4.41 lb
Mounting Wall
Connectors 1 pc. DB 37
Wire terminals 68 pc., screw locked
Unit standard IP 20
Technical Data
20 Hardware for APP700 and APX700 Installation
