Front mount: Cable
This table shows the specifications of the cable.
Table 20
Item Specification
Front panel to I/O unit Double shielded 37 pole
Length 2.0 m
Minimum bend radius 50 mm
Accessories
These are the accessories for the unit:
• Standard software
• Level sensor
• Modem
• Power supply
• Overvoltage protection
• SIOX driver
• RIO modules
• Overlays
Electrical Data
Digital inputs
This table shows the electrical data of the digital inputs.
Table 21
Item
Specification
Isolation Individually opto-isolated
Logic 0 -3 – +5V
Logic 1 1-30V, 6-30 mA
Number 16
Digital outputs
This table shows the electrical data of the digital outputs.
Table 22
Type
Item Specification
Isolation Individually isolated
Total number 8
Relay
Number 6
Type Normally open, unprotected
Max load 2 A, 250V AC/DC
Solid state
Number 2
Technical Data
Hardware for APP700 and APX700 Installation 21
