6 Specification
Motherboard B78 v2.2
CPU Support Intel Celeron M ULV 600MHz/ 1GHz
Chipset Intel 852GM + ICH4
System Memory 256MB DDR RAM, up to 2GB
Graphic Memory Shared system memory up to 64MB
LCD Panel
LCD Size 12.1"TFT 15" TFT
Brightness up to 400 cd / m² 250 - 350 cd / m²
Maximal Resolution 800 x 600 / 1024 x 768 1024 x 768
Touch Screen Type Resistive
Tilt Angle -25° ~ 65°
Storage
HDD 2.5" 40GB or higher
Flash Memory Compact Flash (Type I&II)
Expansion
Mini-PCI Socket
1
Base Rear I / O
USB 4 (V2.0)
Serial/COM
4 x COM ports RJ-45 connectors
(COM1 standard RS-232; COM2 RS232/422/485 selectable by jumper;
COM3 & COM4 pin 9 with 5V or 12V power by jumper)
Parallel 1 x D-sub 25-pin connector
LAN (10 / 100) 1 x RJ45
2
nd
VGA Output 1
Cash Drawer 1 x RJ-11 (12V or 19V ) by jumper
MIC-in 1
Line-out 1
Control/Indicator
Power Button 1
Indicator LED 1
Power
Power Adapter 90W (DC 19V)
Dimension
(W x D x H)
385 X 265 X 384mm 308 X 265 X 356mm
