FUEL BED LAYOUT
Please refer to the relevent section of the user manual section of this booklet.
FITTING THE DECORATIVE FRAME
The appliance is supplied with a decorative frame in a variety of finishes. The frame is held onto the firebox by
four magnets. Ensure the magnets are aligned onto the magnet plates in each corner of the firebox.
TESTING AND COMMISSIONING
Turn on and test the gas supply up to the fire for any leaks, in accordance with current Approved Codes Of
Practice (ACOPs).
SETTING PRESSURE
With the front panel of the fire removed, temporarily re-connect the control knob to the control spindle. To light
the fire, follow the instructions given in section 14.2, bearing in mind that when the front panel of the firebowl is
in position the indicator pip would be at twelve o’ clock in relation to the control knob.
Remove the screw from the pressure test point, situated on the main injector pipe to the left hand side of the
valve, and attach a U gauge. Light the fire on the HIGH setting.
The setting pressure should be in accordance with the figures stated on page 2 of these instructions. The fire is
factory set to achieve these pressures, and any significant variation could indicate a supply problem. If the pres-
sure is too high, the gas supply meter may be set incorrectly. This should be checked with the fire running and if
necessary reset by the gas supplier.
If the pressure is too low, then check the meter governor pressure with the appliance running. If this is incorrect
it will need to be reset by the gas supplier. If the setting pressure is too low, but the meter pressure is acceptable,
then a problem in the supply pipework is to be suspected. This will be dirt and debris, kinked or inadequate size
pipes, restriction in a fitting or solder flashing across a joint. (NOTE: you will not get an accurate reading of the
inlet pressure with a pressure gauge on the end of the supply pipe - this is the static pressure in the system. You
must use a T piece and measure the supply pressure with the fire on High - the dynamic pressure). Refit and tight-
en the screw into the pressure test point when the test is complete.
Refit the front panel of the appliance and secure the control knob to the spindle using the grub screw provided.
Ensure the control markings on the knob line up correctly with the indicator pip on the front panel as detailed in
section 12.1 of these instructions.
When the appliance is first used, protective oils coating the firebox may burn off. It is advisable to ventilate the
room during this period.
