QUADRA
45
E 167 - GB - 6
Rue du Pré Neuf - 58440 MYENNES FRANCE
493 9021
493 9031
POWER SUPPLY :
1)
3 phases 400V :
- The lift can be directly wired.
- No modification required.
- Check the input voltage of the transformer
which must be 400V.
NOTA : The neutral wire is not necessary
for the lift itself. However, it is necessary
for 230V accessories (lighting kits,
wheel alignement device, ...)
2)
3 phases 230V :
- Make the following adjustments.
- Change the transformer.
- Change the position of the electric
coupling 6 terminals of the motor as follow :
400 Volts
230 Volts
Wiring diagram 493 9031
ADD-ON Aux. Type 493 9031
