01041755cvr
FZR4P FZR5P
01041755cvr
FZR4P-T FZR5P-T FZR5PLP-T
Order parts online:
www.follettice.com/healthcare
01191550R01
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com/healthcare
Installation, Operation and Service Manual
Serial numbers K25542 to L28496
FZR4P and FZR5P and FZR5PLP-T
Performance Plus
Undercounter Freezers
Following installation, please forward this manual
to the appropriate operations person.
