Installing Glycerine Solution in Product Simulation Bottle
(glycerine not included - P/N00959296)
1. Remove the bottle from the bracket located in the upper left side
of the refrigerator (Fig. 23).
2. Remove the top and ll the bottle with a 50/50 solution of glycerine
and water.
3. Replace the top (and probe).
4. Reinsert bottle into the bracket.
Note: If you are using this in a food service application, and installing in
accordance with NSF, you must remove the probe from the bottle.
NSF requires that air temperature be displayed.
Fig. 23
Turn on Power
1. Move power switch, located on the bottom left of unit, to the ON
position.
Fig. 24
12 REF4P, REF5P and REF5BBP-T Undercounter Refrigerators
