JP1 (For all models)
JP1
Open
Insert the transmitter
power key
Press and hold
START/AUX
Receiver MAIN
activated
OR
After EMS
reset
Press and hold
START/AUX
Receiver MAIN
activated
JP1
Short
Insert the transmitter
power key
Receiver MAIN
activated
OR
After EMS reset
Re-insert the transmitter
power key
Receiver MAIN activated
* POS (power off stop): JP1 Short
JP2 (For all models)
JP2
Open
5 minutes of transmitter non-usage
Receiver MAIN deactivated
Press any pushbuttons
Receiver MAIN reactivated
JP2
Short
Receiver MAIN stays “on” constantly until the main power source to the system is turn “off”
JP3 (For Alpha 3000F2 & 3000D2 models only)
JP3
Open
Press #1 or #2 (U or D) pushbutton
down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #1 or #2 (U or D) pushbutton
down to the 2
st
speed
Both 1
st
and 2
nd
speed contact relays
engaged (closed)
JP3
Short
Press #1 or #2 (U or D) pushbutton
down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #1 or #2 (U or D) pushbutton
down to the 2
st
speed
Only the 2
nd
speed contact relay is
engaged (closed)
JP3 (For Alpha 3000F3 & 3000D3 models only)
JP3
Open
Pushbutton 1 through 6 interlocked
JP3
Short
Pushbutton 1 through 6 non-interlocked with each pushbutton becomes single-speed contact
JP4 (For Alpha 3000F2 & 3000D2 models only)
JP4
Open
Press #3 or #4 (E or W) pushbutton
down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #3 or #4 (E or W) pushbutton
down to the 2
st
speed
Both 1
st
and 2
nd
speed contact relays
engaged (closed)
JP4
Short
Press #3 or #4 (E or W) pushbutton
down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #3 or #4 (E or W) pushbutton
down to the 2
st
speed
Only the 2
nd
speed contact relay is
engaged (closed)
JP4 (For Alpha 3000F3 & 3000D3 models only)
JP4
Open
No acceleration delay from 1
st
through 3
rd
speed
JP4
Short
1
st
speed
depressed
After 1
second
1
st
speed contact
relay engaged
2
nd
speed
depressed
After 1
second
2
nd
speed contact
relay engaged
3
rd
speed
depressed
After 1
second
3
rd
speed contact relay
engaged
JP5 (For Alpha 3000F2 & 3000D2 models only)
JP5
Open
Press #5 or #6 (N or S) pushbutton
down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #5 or #6 (N or S) pushbutton
down to the 2
st
speed
Both 1
st
and 2
nd
speed contact relays
engaged (closed)
JP4
Short
Press #5 or #6 (N or S) pushbutton
down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #5 or #6 (N or S) pushbutton
down to the 2
st
speed
Only the 2
nd
speed contact relay is
engaged (closed)
Dip-8 (For Alpha 3000D2 model only)
DIP-8
“0”
Press #7 or #8 (AUX↑or AUX↓)
pushbutton down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #7 or #8 (AUX↑or AUX↓)
pushbutton down to the 2
st
speed
Both 1
st
and 2
nd
speed contact relays
engaged (closed)
DIP-8
“1”
Press #7 or #8 (AUX↑or AUX↓)
pushbutton down to the 1
st
speed
1
st
speed contact relay
engaged (closed)
Press #7 or #8 (AUX↑or AUX↓)
pushbutton down to the 2
st
speed
Only the 2
nd
speed contact relay is
engaged (closed)
