As shown above, the dip-switch setting is 10000010 for channel 202.
Number 1 is set as
the write-in
dip-switch. “ON” is
the setting status.
Number 2-8 is the
binary channel selecting
dip-switch. “ON” is “1”
and “OFF” is “0”.
