Fomotech Alpha 608A - Page 28

- 27 -
9
DIP 2,3
→ 00
Momentary relay contact
DIP 2,3
→ 01
Latching/toggle relay contact
DIP 2,3
→ 10
Activate the 3
rd
speed
10
DIP 4
→ 1
Latching/toggle relay contact
→ 0
Momentary relay contact
612D
1 & 2
(2
nd
speed)
DIP 1
→ 1
Both 1
st
and 2
nd
speed contact
relay interlocked when pressed
to 2
nd
speed
Both 1
st
and 2
nd
speed
contact relays activated
→ 0
Both 1
st
and 2
nd
speed contact
relay activated when pressed to
2
nd
speed
Only 2
nd
speed contact
relay activated
---
DIP 2,3,4
→0
Momentary relay contact
DIP2&3 Must set to
“0” all the time
(In-plant set at “0”)
612E
1 & 2
(2
nd
speed)
DIP 1
→ 1
Both 1
st
and 2
nd
speed contact
relay interlocked when pressed
to 2
nd
speed
Both 1
st
and 2
nd
speed
contact relays activated
→ 0
Both 1
st
and 2
nd
speed contact
relay activated when pressed to
2
nd
speed
Only 2
nd
speed contact
relay activated
7 & 8
DIP 2
→ 1
Not Interlocked
→ 0
Interlocked
7
DIP 3
→ 1
Latching/toggle relay contact
DIP2 Set at “1”
→ 0
Momentary relay contact
612
A/B/C/D/E
11
DIP 7
→ 1
Latching/toggle relay contact
→ 0
Momentary relay contact
12
DIP 8
→ 1
Latching/toggle relay contact
→ 0
Momentary relay contact
※
※
In-plant all set at “0”
