Fomotech Alpha 608A - Alpha 604;607;608;612 Spare Parts; Battery Charger

- 7 -
1
2
3-1
4
3-2
3.2 Alpha 604/607/608/612 Spare Parts
3.3 Battery Charger
(1) Charger power status: green light
(2) Charging status: green/red light
(3-1) Power input socket AC100-240V
(3-2) Power input socket DC12-24V
(4) Charger holder (optional). Please refer to
below figure for the installation holes.
(1) Charging cable
(2) Charger (optional)
(3) Transmitter shock-absorbing rubber
(4) Shoulder strap
(5) Rechargeable batteries (optional)
(Fig.4) Battery Charger
& Holder
