- 36 -
Receiver system Status LED Display
Type
Led Indication
Problem and Solution
1
Constant red light.
EEPROM error – reprogramming required.
Incorrect receiver ID code setting (see note below).
2
ON → 1.0 second
OFF → 1.0 second
ID code not matched on both the transmitter and
receiver unit, please readjust accordingly.
3
Dim or no light.
Under-voltage, check the main power-supply.
4
ON → 2.0 seconds
OFF → 0.1 second
MAIN contact relay jammed or defective.
5
ON → 0.1 second
OFF → 2.0 seconds
System normal with transmitter pushbutton either in
neutral or in transmitter power “off” position.
6
ON → 0.1 second
OFF → 0.1second
System normal with transmitter pushbutton in
non-neutral position (pushbutton depressed).
Note: Please refer to section 7.1 on page 20 for correct ID code setting.
Alpha 612 Receiver System Status LED Display
Led Indication
Reason
Solution
Power LED display
ON
Normal-voltage
OFF
Under-voltage
SQ, Status LED display
ON
Transmitted signals detected
and received
OFF
No transmitting signal detected
BLINK
1.Transmitter standby
Turn on the transmitter
2.Interference
Turn off the transmitter
Relay LED display
ON
Normal operation
OFF
Receiver defective
Repair decoder board
