10
TEST SLOT
Insert test strip here to turn the
monitor on for testing.
DISPLAY SCREEN
RF BUTTON (For FORA D40b and
D40g)
Assists you with wireless data
transmission.
AVERAGE BUTTON (For FORA
D40a)
Assists you with blood pressure
average mode.
S BUTTON
Enter and confirm the monitor
settings.
M BUTTON
Enter the monitor memory.
ON/OFF BUTTON
To start a single blood pressure
measurement.
USER SELECTION BUTTON
Assist you with user number
selection.
SPEAKER
RF INDICATOR
Indicates a wireless data trans-
mission.
1
3
4
2
6
10
14
11
15
12
16
17
13
18
19
8
5
9
7
USB INDICATOR
Indicates when a USB cable
plug inserted.
POWER INDICATOR
Indicates the power status of
the device.
BATTERY COMPART-
MENT
AC/DC ADAPTER PORT
Connect to a power supply.
USB LINK PORT
Download test results with a
cable connection.
STRIP EJECTOR
Eject the used strip by push-
ing up this button.
AIR JACK
PRESSURE CUFF
AIR TUBE
AIR PLUG
Connect to air jack.
