5.0 AIRFLOW PERFORMANCE
Airow performance data is based on cooling performance with a coil and no lter in place.
Selecting the appropriate unit size performance table for external static applied to the unit
allows operation within the minimum and maximum limits shown in the table below for both
cooling and electric heat operations.
AIRFLOW PERFORMANCE DATA
MODEL SPEED
CFM (W)
EXTERNAL STATIC PRESSURE - kPa (inch WC)
0
0.02
(0.1)
0.04
(0.16)
0.05
(0.2)
0.07
(0.3)
0.10
(0.4)
0.12
(0.5)
0.15
(0.6)
0.17
(0.7)
0.20
(0.8)
24
LOW
CFM 646 623 602 592 553 506 453 – – –
RPM 528 591 628 650 728 790 840 – – –
WATT 169.4 166.4 164.5 163 157.5 151.3 146.3 – – –
AMP 0.79 0.78 0.78 0.78 0.77 0.76 0.75 – – –
MED
CFM 815 802 786 771 733 681 613 – – –
RPM 658 701 732 743 790 841 888 – – –
WATT 218 216.6 215.9 214.4 211.4 207.4 203 – – –
AMP 0.96 0.95 0.95 0.95 0.94 0.93 0.92 – – –
HIGH
CFM 1043 993 965 947 920 866 780 695 607 515
RPM 741 769 788 802 837 876 919 956 986 1014
WATT 286.8 279.4 275.6 271.3 267.5 265.4 262.6 256.4 250.1 243
AMP 1.30 1.28 1.26 1.25 1.24 1.22 1.20 1.18 1.17 1.15
36
LOW
CFM 1129 1088 1061 1040 988 941 819 – – –
RPM 642 675 706 732 771 817 853 – – –
WATT 322 312 306 301 289 269 254 – – –
AMP 1.54 1.52 1.51 1.50 1.47 1.42 1.39 – – –
MED
CFM 1317 1268 1237 1217 1157 1111 1027 – – –
RPM 776 810 841 874 905 935 966 – – –
WATT 360 354 348 345 335 323 309 – – –
AMP 1.69 1.67 1.66 1.65 1.63 1.60 1.57 – – –
HIGH
CFM 1643 1581 1544 1518 1446 1356 1261 1123 915 812
RPM 868 883 895 906 931 955 978 1013 1028 1050
WATT 463 451 443 438 429 415 401 371 356 343
AMP 2.22 2.20 2.18 2.17 2.14 2.12 2.09 2.03 1.99 1.96
48
LOW
CFM 1471 1427 1395 1374 1316 1247 1180 – – –
RPM 694 732 753 769 803 833 864 – – –
WATT 381 376 372 370 364 357 349 – – –
AMP 1.66 1.64 1.63 1.62 1.60 1.58 1.55 – – –
MED
CFM 1729 1678 1646 1625 1558 1491 1402 – – –
RPM 790 817 833 845 876 898 920 – – –
WATT 485 477 473 470 460 451 440 – – –
AMP 2.14 2.12 2.09 2.08 2.06 2.03 1.99 – – –
HIGH
CFM 2045 1992 1951 1928 1847 1763 1677 1563 1450 1317
RPM 895 920 932 938 956 972 987 1002 1015 1030
WATT 641 627 617 612 596 582 566 546 528 507
AMP 2.86 2.82 2.80 2.78 2.73 2.68 2.64 2.57 2.52 2.45
60
LOW
CFM 1786 1740 1709 1688 1630 1562 1489 – – –
RPM 830 843 849 856 890 921 942 – – –
WATT 584 569 560 552 536 516 497 – – –
AMP 2.64 2.59 2.55 2.54 2.58 2.42 2.37 – – –
MED
CFM 2140 2071 2039 2006 1932 1799 1677 – – –
RPM 917 930 938 943 957 970 990 – – –
WATT 645 630 623 617 602 585 569 – – –
AMP 2.87 2.81 2.78 2.76 2.71 2.65 2.59 – – –
HIGH
CFM 2357 2276 2225 2188 2100 2004 1902 1764 1554 1393
RPM 964 976 982 990 1000 1012 1022 1032 1042 1063
WATT 754 733 718 710 693 673 650 630 607 575
AMP 3.34 3.27 3.22 3.19 3.12 3.05 2.98 2.91 2.83 2.71
