230 V / 60 Hz
CONNECTING PIPE
WATERPROOF COVERSIGNAL CORD
DRAIN TUBE
The left side of the unit must be
have 45 to 50 cm (17 23/32" to
19 11/16") of clearance, 10 cm
(4") at the back
HIGH PRESSURE VALVE
LOW PRESSURE VALVE
SERVICE VALVE
10 cm
50 cm
Installation Master Plan
