4.1 Control Panel & Ignition
This chipper is fitted with an engine PLC (Programmable Logic Controller) system
that manages the engine, feed and all safety features. The control panel is located
on the right-side panel. Feed and engine speed are controlled with a “No Stress”
function ensuring that cutting conditions are kept within optimum limits. This
maximises throughput while minimising jams and blockages. There will be times
when material is being cut and the feed will momentarily stop until engine speed
increases. At this point, the feed will start without warning. Service warnings shown
below will be displayed at certain intervals. The engine will not start until OK is
pressed.
• First 20 Hour Warning: "Change Hydraulic Oil Filter"
• Every 20 Hour Warning: "Blade and Machine check required see manual"
• 50 Hour Service Warning: "1st Full Service recommended"
• Every 200 Hour Service Warning: "Full Service recommended"
4.1.1 Control Panel
