FORST TR8D - Page 18

Page 18
P2 shows I/O tests. Tests all functions and safety controls.
Pin screen
P3 shows No-Stress Settings
• Actual RPM
• Upper Band - 1400 RPM
• Mid Band – 1125 RPM
• Lower Band – 925 RPM
•
Pin screen automatically displays if any setting changes are attempted.
P4 shows Pre-Heat Settings
• Enable Pre-Heat – True
• Pre-Heat Time – 10
• Crank Time – 3
To stop engine, turn off with ignition key
by turning fully anti-clockwise.
