FORST XR8P - Track Control and Driving

P a g e | 18
Figure 6
Track control and driving
Figure 7
1
SLACKEN OR REMOVE SPRING
TENSIONER NUTS BOTH SIDES
BEFORE LIFTING FEED ROLLER
2
INSERT TOP FEED ROLLER LIFTING
TOOL INTO SLOT AND LIFT
3
INSERT M12 SCREW TO HOLD FEED
IN OPEN POSITION
