FORST XR8P - Hydraulic Oil Filter

P a g e | 32
Hydraulic oil filter
Use protective plastic gloves to keep oil off skin, dispose of oil and filter in an
environmentally responsible manner.
1
SIDE ANVIL
2
ANVIL
3
OUTSIDE BLADE GAP
4
FLYWHEEL BLADE
5
INSIDE BLADE GAP
Item Description Quantity
1 Complete filter 1
2 Filter element 1
3 Seal kits 1
3a O-ring for filter element 1
3b O-ring for housing 1
3c Anti-extrusion ring 1
3d Gasket 1
3e O-ring 1
3f Protection seal 1
4 Indicator plug 1
