Configuring L2TP PPTP and L2TP VPN
Figure 30: Sample L2TP address range configuration
To add source addresses
Add a source address for every address in the L2TP address range.
1 Go to Firewall > Address.
2 Select the interface to which L2TP clients connect.
3 Select New to add an address.
1 Enter the Address Name, IP Address, and NetMask for an address in the L2TP
address range.
2 Select OK to save the source address.
3 Repeat for all addresses in the L2TP address range.
To add a source address group
Organize the source addresses into an address group.
1 Go to Firewall > Address > Group.
2 Add a new address group to the interface to which L2TP clients connect.
3 Enter a Group Name to identify the address group.
The name can contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and
the special characters - and _. Other special characters and spaces are not allowed.
4 To add addresses to the address group, select an address from the Available
Addresses list and select the right arrow to add it to the Members list.
5 To remove addresses from the address group, select an address from the Members
list and select the left arrow to remove it from the group.
6 Select OK to add the address group.
Note: If the L2TP address range is comprised of an entire subnet, add an address for this
subnet. Do not add an address group.
