1.5 Physical Description
1.5.1 Front Panel
Front Panel for FI9804W/FI9805W/FI9805E
Figure 1.1
1 WIFI Antenna: Wireless Antenna (FI9804W, FI9805W)
2 Infrared LED: 12 IR LEDs (FI9804W), 36 IR LEDs (FI9805W, FI9805E)
3 LENS: CMOS sensor with fixed focus lens
4 Induction IC
Front Panel for FI9803
Figure 1.2
1 Infrared Lamp Array
2 LENS: CMOS sensor with fixed focus lens
3 Induction IC
2
3
4
1
