Foscam FI9803 - FI9804 W Specifications

www
www
.foscam.co
.foscam.co
m
m
Shenzhen
Shenzhen
Foscam
Foscam
Intelligent
Intelligent
Technology
Technology
Co.,
Co.,
Limited
Limited
Tel:
Tel:
86
86
755
755
2674
2674
5668
5668
Fax:
Fax:
86
86
755
755
2674
2674
5168
5168
82
Firewall Supports IP Filtering
Reset Reset button is available
Power
Power Supply DC 12V/1.0A
Power Consumption 5.5 Watts (Max.)
Physical
Dimension(mm) 153(L)x 92(W)x 86(H)
Gross Weight 696g
Net Weight 380g
Environment
Operating Temperature -20°~ 55°C (-4°F ~ 131°F)
Operating Humidity 20% ~ 85% non-condensing
Storage Temperature -20°C ~ 60° (-4°F ~ 140°F)
Storage Humidity 0% ~ 90% non-condensing
Certification CE, FCC, RoHS
Warranty Limited 2-year warranty
ITEMS FI9804W
Image Sensor Sensor High Definition Color CMOS Sensor
Display Resolution 1.0 Megapixels
Min. Illumination 0 Lux (With IR Illuminator)
Lens
Lens Type Glass Lens
focal length f:2.8mm
Aperture F1.2
Angle of View 70°
Video
Image Compression H.264
Image Frame Rate 30fps(60Hz), 25fps(50Hz), downward adjustable
Resolution 720P(1280 x 720), VGA(640 x 480), QVGA(320 x 240)
Stream dual stream
Image adjustment The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image flip and mirror
Infrared mode Automatic or manual
Night visibility 12pcs IR-LEDs, night vision range up to 20 metres
Audio Input/Output External standard 3.5mm interface for two-way audio
Audio Compression PCM/G.726
Network
Ethernet One 10/100Mbps RJ45 port
Wireless Standard IEEE802.11b/g/n
Data Rate IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security WEP, WPA, WPA2
Network Protocol IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS,
UPnP, RTSP, ONVIF
Operating System Microsoft Windows 2000/XP, Vista, 7;
Mac OS
