IP. (For more details see: How to add cameras in WAN)
6.2 Default Parameters
Default network Parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
DDNS: Embedded FOSCAM domain name
Username and password
Default username is admin with a blank password
6.3 Specifications
ITEMS FI9816P
Image Sensor
Sensor High Definition Color CMOS Sensor
Display Resolution 1280 x 720 (1Megapixels)
Min. Illumination 0 Lux (With IR Illuminator)
Lens
Lens Type Glass Lens
focal length f:2.8mm
Aperture F2.4
Angle of View 70°
Video
Image Compression H.264
Image Frame Rate 30fps maxmium, downward adjustable
Resolution
720P(1280 x 720), VGA(640 x 480), VGA(640 x 360),
QVGA(320 x 240), QVGA(320 x 180)
Stream dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image flip and mirror
Infrared mode Automatic or manual
Pan/Tilt Angle Horizontal:300° & Vertical: 120°
Night visibility 11pcs IR-LEDs, night vision range up to 8 metres
Audio
Input/Output
Supports two-way audio
Built-in Mic & Speaker
3.5mm audio jack for external Mic & Speaker
Audio Compression PCM/G.726
Network
Ethernet One 10/100Mbps RJ45 port
Wireless Standard IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security WEP, WPA, WPA2
