Foundations LX6 - Assembly Instructions; Tools, Parts, and Warnings

Parts ( Color and Style may vary)
Assembly Instructions
TOOLS REQUIRED: Phillips screwdriver
• Read all instructions before ASSEMBLY and USE of Stroller.
• Unpack carton, remove packing materials, including polybag. Identify and check all parts.
If parts are missing or damaged, call Foundations
®
for assistance at 877.716.2757
(USA Only) or 330.722.5033.
• Discard all packing materials after assembly.
• Choking Hazard - Stroller assembly hardware includes small
parts. Keep small parts away from children.
• Plastic bags can cause su󰀨ocation. Keep plastic bag away from
children. Remove and discard plastic bags.
• Pinch Hazard - Keep hands clear of moving parts during
assembly, folding and unfolding.
A
Stroller Frame
Assembly (1)
Rear Wheel
with Axle (2)
C
Rear Axle Tube
Assembly (1)
E
Arm Bar (1)
F
Canopy (1)
H
Screw [M6 x 34 mm] (2)
Nut [M6] (2)
WARNING
4
G
Rear Basket Tube (1)
K
Shoulder Screw [M6 x 25 mm] (2)
I
L
Lock
Washer (2)
M
Flat Washer
[6.2x20x1 mm] (2)
N
Canopy Handle
Cover (2 Installed)
B
D
Front Wheel
Assembly (2)
