D
ESCRI PTI ON
OF
H
ARDWARE
February 2003 © 2003 Foundry Networks, Inc. 2-7
Power Supply Receptacle
The power receptacle is located on the rear panel of the switch.
The standard power receptacle is for the AC power cord.
Diag On Green The system diagnostic test has
completed successfully.
Flashing
Green
The system diagnostic test is in
progress.
On Amber The system diagnostic test has detected
a fault.
Link N/A This indicator is not currently
implemented.
Duplex N/A This indicator is not currently
implemented.
Stack Flashing
Amber
An initial state of stacking configuration
upon powering on.
Green This switch is acting as the master unit
in the stack.
Amber This switch is acting as a slave unit in
the stack.
Flashing
Green
When the user enters the light unit
command in the CLI, the unit ID of each
switch in the stack will be displayed by
port LEDs 1 to 8.
System Status LEDs
LED Condition Status
