3
27



-
ers design and build CPU architecture systems with two or more processors. MPS 1.1 was


MPS 1.4 introduces support for a secondary PCI bus without requiring a PCI bridge. If your
operating system comes with support for MPS 1.4, you should keep the setting as the default
1.4. You also need to enable MPS 1.4 support if you need to make use of the secondary PCI
bus on a motherboard that doesn't come with a PCI bridge. You should only leave it as 1.1
only if you are running an older operating system that only supports MPS 1.1.

This item is used to set the PCI latency timer. The value is in unit of PCI cycle for PCI device
latency timer register. Setting values are 32, 64, 96, 128, 160, 192, 224, 248.
This feature controls how long each PCI device can hold the bus before another takes over.
The larger the value, the longer the PCI device can retain control of the bus. Low values for
the PCI Latency Timer will reduce the effective PCI bandwidth while higher values means
every PCI device will have to wait longer before they can get access to the bus, but when they
do get access, they can conduct their transactions for a longer time. Normally, a default value
of 64 cycles is set. Some PCI devices may not agree with longer latency times so if you start
facing problems like stuttering sound or a less responsive system, reduce the latency. Higher
values will actually reduce performance as too much time may be allocated to each PCI de-
vice
to the disadvantage of other devices on the bus.

This item is used to enable/disable the quiet boot.



Advanced BIOS Features
      
 
  
  
 

F9:Optimized Defaults


Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Foxconn G41MD Series and is the answer not in the manual?

Foxconn G41MD Series Specifications

General IconGeneral
Form FactorMicro ATX
CPU SocketLGA 775
Expansion Slots1 x PCIe x16, 1 x PCIe x1, 2 x PCI
Onboard VideoIntel GMA X4500
ChipsetIntel G41
Memory Slots2
Storage Interface4 x SATA 3Gb/s
AudioRealtek ALC662 6-Channel HD Audio
Rear Panel I/O Ports1 x PS/2 keyboard, 1 x PS/2 mouse, 1 x VGA, 4 x USB 2.0, 1 x RJ-45, 3 x audio jacks
USB Ports4 x USB 2.0 (rear), 4 x USB 2.0 (via headers)
Video Outputs1 x VGA
