4.2LimitSetting-SystemTemperature
This page lets you to set system high limit temperature and enable the alert function.
4.3LimitSetting-CPUFan
This page lets you to set CPU fan low limit rpm and enable the alert function.
Set high limit by
dragging the lever
Show current system
temperature value
Enable alert function
when the system
temperature is higher
than high limit value
Show current high
limit value of system
temperature
Set low limit rpm by
dragging the lever
Show current CPU
fan rpm value
Enable alert function
when the CPU fan runs
slower than the low
limit rpm value
Show current low limit
rpm value of CPU fan
