CD INSTRUCTION
52
4.4LimitSetting-SystemFan
This page lets you to set system fan low limit rpm and enable the alert function.
4.5LimitSetting-FAN1Fan
This page lets you to set FAN1 fan low limit rpm and enable the alert function.
Set low limit rpm by
dragging the lever
Show current FAN1
fan rpm value
Enable alert function
when the FAN1 fan
runs slower than low
limit rpm value
Show current low limit
rpm value of FAN1 fan
Set low limit rpm by
dragging the lever
Show current system
fan rpm value
Enable alert function
when the system fan
runs slower than low
limit rpm value
Show current low limit
rpm value of system
fan
