■ DCT channels A and B can be ganged as a single logical 128-bit DIMM.
■ Offers highest DDR3 bandwidth.
■ Requires both DIMMs in a logical pair to have identical size and timing parameters, both
DCTs programmed identically.
Unganged channels
■ DCT channels A and B operate as two completely independent 64-bit channels (both chan-
nels operate at the same frequency).
■ Reduce DRAM page conicts – more concurrent open dram pages .
■ Better bus efciency.
Burst lengths supported
When both DCTs are enabled in unganged mode, BIOS must initialize the frequency of each
DCT in order.
DRAM Timing Conguration
CMOS Setup Utility - Copyright (C) 1985-2011, American Megatrends, Inc.
DRAM Timing Configuration
DRAM Timing Configuration
Help Item
Memory Clock Mode
[Auto]
DRAM Timing Mode [Auto]
Auto
Limit
Manual
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Auto]
Options
► Memory Clock Mode
This option is used to conguration Memory Frequency, Timings and Subtimings. Setting
values are :[Auto],[Limit],[Manual].
[Auto]: DRAM SPD prole1;
[Limit]: DRAM SPD prole2;
[Manual]: DRAM by Manual.
► DRAM Timing Mode
When both DCTs (DRAM controller) are enabled in unganged mode, BIOS must initialize the
frequency of each DCT in order, you also can congure the timings manually.
Settings are: [Auto], [DCT0], [DCT1], [Both].
