Foxconn M61PML Series - Superio Configuration

3
31
SuperIO Conguration
CMOS Setup Utility - Copyright (C) 1985-2011, American Megatrends, Inc.
SuperIO Conguration
Configure ITE8728 Super IO Chipset Help Item
Serial Port1 Address
Allows BIOS to select
OnBoard CIR Port [3E0] serial port1 base
CIR Port IRQ [IRQ10] address.
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[3F8/IRQ4]
► Serial Port1 Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 1.
► OnBoard CIR Port
This item is used to setup the value of the onboard CIR port.
► CIR Port IRQ
This item is used to setup the interrupt request (IRQ) of the onboard CIR port.
