Foxconn M61PML Series User Manual

1
2
CPU Support AM3 socket processors (PhenomII, dual power plane)
Max processor power up to 95W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
HyperTransport Hyper Transport 1.0 interface
Chipset MCP61P
Memory 2 x 240-pin DDR3 DIMMs
Support up to 8GB of system memory
Dual channel DDR3 1333/1066 MHz architecture
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
VGA NVIDIA Radeon HD 6100 Graphics
Support Direct X 9 compliant
Storage
MCP61P chipset:
- 4 x SATA connectors
- 300MB/s data transfer rate
- Support RAID 0, 1 and 10
- Support hot plug and NCQ (Native Command Queuing )
LAN
Realtek RTL8201 10/100Mb/s PHY LAN chip
(co-lay Realtek RTL8211 10/100/1000Mb/s PHY Gigabit LAN chip)
Audio Realtek ALC662 audio chip:
- High Denition Audio
- 2/4/5.1-channel
- Support Jack-Sensing function
USB Support hot plug
Support up to 8 x USB 2.0 ports (4 rear panel ports, 2 onboard USB
headers supporting 4 extra ports)
Support USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA connectors
2 x USB 2.0 connectors (supporting 4 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front Audio connector
1 x Front panel connector
1 x CD_IN connector
1 x CIR connector
1 x Chassis intrusion alarm header
1-1 Product Specications
(Continued on the next page)

Foxconn M61PML Series Specifications

General

Brand	Foxconn
Model	M61PML Series
Category	Motherboard
Language	English
