System Information
This submenu is used to set up the standard BIOS features, such as the date, time, oppy drive
and so on. Use the arrow up/down keys to select an item, then use the <+> or <-> keys to change
the setting.
► Date - <weekday><month><date><year> format
Day—weekday from Sun. to Sat., automatically displayed by BIOS (Read Only).
Month—month from 1 to 12.
Date—date from 1st to 31st.
Year—year, set up by users.
Use <Enter>, <Tab> keys to select a eld. Use <+>, <->, <PageUp> or <PageDown> to select
a value.
► Time - <hour> : <minute> : <second> format
This item allows you to congure the desired time. Use <Enter>, <Tab> to move forward and
select a eld. Directly input a value or use <PageUp>, <PageDown>, <+> or <-> to select a
value.
► IDE Channel Master / Slave
These categories identify the hard disks connected to the PATA port in the system.
In each channel’s display, you can press [Enter] to go to its submenu. You can further
congure specic drive settings. [None] and [Auto] settings allow you to enable or disable this
drive. [None] means no HDD is installed or set, and [Auto] means the system can auto-detect
the hard disk when booting up. In Access Mode setting, selections of [CHS], [LBA], [Large] and
[Auto] can help you to select hard drive for legacy compatibility.
Award (Phoenix) BIOS can support 3 HDD modes: CHS, LBA and Large.
Note: Set to [Auto] , the system can detect the hard disk and select the HDD mode
automatically. Suggest you select this option.
Phoenix - AwardBIOS CMOS Setup Utility
System Information
Date (mm:dd:yy) Wed, Dec 12 2007 ▲ Item Help
Time (hh:mm:ss) 17 : 44 : 13 █
█ Menu Level ►
► IDE Channel Master [HDS728080PLAT20][HDS728080PLAT20] █
► IDE Channel Slave [DVD-ROM DDU1642][DVD-ROM DDU1642] █ Press [Enter] to enter
► SATA Channel 1 Master [ None] █ next page for detail
► SATA Channel 2 Msater [ None] █ hard drive settings.
► SATA Channel 3 Master [ None] █
► SATA Channel 4 Master [ None] █
█
Drive A [1.44M, 3.5 in.] █
Halt On [All , But Keyboard] █
█
Model Name MCP73M06 █
BIOS ID MCP73M06-GAR.F1.D.11 █
BIOS Version 794F1P01 █
CPU Name Genuine Intel(R) CPU █
@ 2.66GH� ▒
Memory 1024M ▼
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
HDS728080PLAT20
CHS For HDD <528MB
LBA For HDD >528MB & Supporting LBA (Logical Block Addressing)
Large For HDD>528MB but not supporting LBA
